FEATURES


• New technology for dirt removal.

• Uses Pall rings instead of perforated sheet strainer

• PP Pall rings provide minimal resistance to fluid flow. • Compact size.

• Provision to install auto airvent at top to remove air

• Separation of dirt particles heavier than water is facilitated by:

- Low water velocity

- Deflection of fluid stream in many different directions by the pall rings

- Creation of non-turbulent zone in the extended lower part

BENEFITS

• Removes impurities heavier than water:

- Prevents choking of strainers.

- Prevents damage to pumps and other equipment.

• Low pressure drop.

• Better dirt removal than perforated sheet strainer

• It is clog resistant and does not require system shut down or to bypass the system to clean it.

• No need to open the top cover and to remove strainer for cleaning

• Debris, lighter than water, which generally chokes the perforated strainer floats to the top and can easily be removed by opening top dead plug and draining the water.

TECHNICAL DATA

Connection sizes                                   :           80-800 mm dia

Material

Shell                                                      :           Carbon Steel

Pall rings                                               :           PP

Max. operating pressure                       :           16 Bar

Working temperature range                  :            0°C-1 20°C
